E9 Automatic Electrostatic Powder Coating Gun E9
Automatic gun from the E series, suited to conveyor-line automatic coating of mostly standard workpieces, built on the same technical platform as the E series manual guns.
1 / 3Technical Specifications
| Model | E9 |
|---|---|
| Type | Automatic |
| Category | Electrostatic Powder Coating Gun |
| Input Voltage | AC 220V 50Hz |
| Power | — |
| Hopper | Powder feed system configured to line requirements |
| Suitable Workpieces | Conveyor-line batch coating, standard workpieces on automatic lines |
| Status | In Production |
Key Features
- E series platform: Shares its platform with E series manual guns — proven technology and interchangeable spare parts.
- Automatic-line ready: Standard reciprocator interface; installs directly on both new lines and retrofitted lines.
- Easy maintenance: Simple structure; on-site operators can handle routine upkeep after basic training.
Specifications
| Item | Parameter |
|---|---|
| Input voltage | AC 220V 50Hz |
| Output current | 0–100μA adjustable |
| Air consumption | ≤0.3m³/min |
| Nozzle options | Round, flat, extension wand |
| Mounting | Reciprocator / fixed bracket |
For detailed specifications, refer to the latest product manual. Contact us for the full parameter sheet.
Typical Applications
Conveyor-line automatic coating of mostly standard workpieces; entry-level automatic lines with limited budgets that prioritize stability and easy maintenance.
FAQ
Q: How do I choose between the E9 and E7 automatic guns? Their positioning is similar; the choice depends on your line configuration and workpieces. Contact us with workpiece photos and chain speed, and we will provide a comparison plan.
Want to Confirm This Model Fits Your Workpieces?
Provide workpiece dimensions, material and daily output — we deliver selection advice and a configuration list. Sample spray testing available.
